Get Acquainted With EU Safety Glove Standards
The classification of a glove in a particular test is usually defined as one of a series of performance levels. It is left to the user, following a suitable risk assessment exercise, to select a glove with a suitable profile.
- By Simon Courtney
- Feb 01, 2016
Gloves are available to protect hands and forearms from cuts, abrasions, burns, cold, puncture wounds, vibration, skin contact with hazardous chemicals, and some electrical shocks. The nature of the hazard, the associated risk, and the type of operation involved will affect the selection of gloves, and it is essential that gloves are chosen that are designed for the specific application. Gloves designed to protect against one hazard may not protect against a different one even though the gloves may appear similar.
To support this wide range of applications, CEN (the European Standards body) has developed a corresponding series of standards. Use of these standards assists glove manufacturers and suppliers in obtaining the CE Mark indicating the gloves' compliance with EU legislation. Two general standards, EN 420:2003 and EN 388:2003, are called up in many of the other standards.
General Requirements of EN 420:2003 + A1: 2009—Protective Gloves
This standard is designed to ensure that the gloves themselves do not cause harm to the wearer and are comfortable to wear. Tests and requirements include the pH and chromium VI content of leather, determination of extractable protein content of latex, plus water vapor transmission and absorption of materials. In addition, procedures to examine the sizing of the glove and its effect on finger dexterity are covered, plus general requirements for the information to be supplied with and marked on the glove.
EN 420, 4.2—Resistance of Glove Materials to Water Penetration
Resistance to water penetration is an optional test property that is assessed if it is required, according to the intended use of the gloves. For leather gloves, a sample of the leather is subjected to a penetrometer test, where it clamped to circular clamps and flexed in a trough of water. The leather is flexed until water penetrates from the outer side of the leather to the inner side and is recorded as the number of minutes to penetration.
Four levels of performance are defined within EN 420, ranging from Level 1 (which is equivalent to penetration occurring between 30 and 60 minutes) to Level 4. An alternative, more applicable test is used to assess textile materials. This method uses hydrostatic head equipment, which applies a column of water at steadily increasing pressure to the outer surface of the gloving material until penetration of water through to the inner surface occurs. The results for this test are recorded as the pressure required to cause penetration and are recorded in Pascals. EN 420 does not contain a requirement for this test but requires that the level of resistance is communicated to the customer.
There is unfortunately no correlation between the results obtained through these different test methods.
EN 420, 4.3.2—Determination of pH Value
The pH value of a material is an indication of how acidic or alkaline it is, measured using the pH scale from 1 to 14. A measurement of 1 is strongly acidic, and 14 is strongly alkaline. The scale is logarithmic, which means that each whole scale point is equivalent to a tenfold change in acidity or alkalinity.
Skin irritations can occur if a material in a PPE product has a very high or very low pH value, and particularly if the acids or alkalis present are "strong"—that is, if they are highly ionized. For gloves of materials other than leather, the material must have a pH value of between 3.5 and 9.5, thus excluding extremes of acidity and alkalinity. For gloves made from a number of layers, the layers must be assessed.
EN 420, 4.3.3—Determination of Chromium VI Content
This test is applicable to leather gloves only. Chromium is a transition metal, the salts of which are used in leather tanning. In leather it can exist in two forms (or "valency states") known as chromium III (trivalent chromium) and chromium VI (hexavalent chromium). In the finished leather, it is usually present as chromium III. It is possible, however, that during the tanning process or under certain storage conditions, small amounts of chromium III can be oxidized to chromium VI—a known skin irritant, potential carcinogen, and environmental hazard. Chemical innocuousness testing of leathers requires that there is no detectable chromium VI present. The upper limit of detectable chromium VI is quoted as 3 ppm. If a level below this is detected, no detectable chromium VI is present as defined by the detection limit.
EN 420, 4.3.4—Determination of Extractable Protein Content of Latex Products
Natural latex proteins are known to cause allergic reactions in many people. One common product where latex is used is in medical examination gloves for single use. The nature of this product causes the wearer and the patient to have direct skin contact with the latex. This means that the issue of allergies must be considered as part of the chemical innocuousness testing. The test data are required to be marked on the product or the packaging, in order to allow the end user to make an informed choice of a suitable product.
EN 420, 5.3—Dexterity
A glove should allow as much dexterity as possible given its purpose. This property is assessed by using a panel of users who try to pick up cylindrical pins of varying diameters, from 5 to 11 mm, while wearing the gloves. EN 420 contains five levels of performance ranging from Level 1, where the wearer is able only to pick up a pin with a diameter of 11 mm, to Level 5, where the wearer is able to pick up the smallest pin of 5 mm diameter.
EN 420, 5.3—Water Vapor Transmission and Absorption
The standard states that, where practicable, protective gloves shall allow water vapor transmission to aid comfort by allowing perspiration to escape the glove, therefore aiding wearer comfort.
Obviously, molded rubber or polymeric gloves will not allow water transmission, and hence this property is not relevant. For other types of gloves, the water vapor transmission is assessed by clamping a sample of material in the mouth of a bottle containing a solid desiccant and is kept in a rapid current of air in a conditioned room. The air within the bottle is circulated by keeping the desiccant in motion. Weight gain of the bottle is caused by the desiccant absorbing moisture from the air that has transmitted through the material. The results are expressed in units mg/(cm2/h), and EN 420 requires that the materials possess a water vapor transmission of at least 5 mg/(cm2/h).
For materials where the glove construction and material inhibits water vapor transmission, then the glove shall reduce the effects of perspiration by being absorbent. This property is assessed by clamping a sample of material over the mouth of a sealed container over a reservoir of water. During the test, water vapor is absorbed from the air within the container and is expressed in mg/cm2. EN 420 requires that the glove has a water vapor absorption of at least 8 mg/cm2 when tested for eight hours.
EN 388:2003—Protective Gloves Against Mechanical Risks
The EN 388:2003 standard is intended to assess a glove's ability to protect against mechanical hazards such as cutting. It includes a series of four tests that measure the glove's resistance to abrasion, cutting, tearing, and puncture.
EN 388, 6.1—Abrasion Resistance
The abrasion resistance test is undertaken on a Martindale wear and abrasion machine in which specimens of the material (cut from the palm of the glove) are fitted to a rubbing head of fixed size and weight. This head is then moved in an elliptical motion over a table covered with 100 grit abrasive material. Four specimens of the material are tested, with the test result being the number of cycles required to abrade through (hole) the material. The performance level of a single material is decided by the lowest result of the four tests. For multiple-layer materials (where the test specimen is made of several unbonded layers), each layer is tested separately. The performance level is based on the sum of the number of cycles.
Four levels of performance are defined within EN 388, ranging from Level 1 (which is equivalent to holing between 100 and 500 cycles) to Level 4 (where holing does not occur before 8,000 cycles).
EN 388, 6.2—Blade Cut Resistance
This test consists of a circular, free, rotating blade under a standard 5N contact force that tracks backward and forward over the flat surface of the test material within a fixed stroke length. The test stops when cut-through of the blade is detected via electrical contact with the underlying surface, and the number of strokes completed by the blade is recorded. To take the sharpness of the blade into account, the test is performed using a standard canvas control material both before and after testing the specimen. The mean of these two tests on the control material is then calculated. The test result is determined from the number of cycles required to cut through the specimen and the mean number of cycles required to cut through the control fabric.
Where multiple layer materials are present, the layers are assembled and tested as they would be in the glove. Two test specimens are selected, and each specimen is tested five times, allowing for any variation across the specimen. A mean blade cut index is calculated from the five tests. The performance level is based on the lower mean blade cut index of the two specimens, ranging from a Level 1 cut resistance of greater than 1.2 up to a Level 5, with a result greater than 20.
For all higher-level cut-resistant materials (Levels 4 and 5), it is permissible to use the ISO 13997:1999—‘Protective clothing—Mechanical properties—Determination of resistance to cutting by sharp objects’ cut test as an alternative.
This alternative test uses a straight blade drawn across a specimen until cut-through takes place. The test measures the load applied to the blade in order to make a cut-through over a 20 mm stroke length. Because the blade travels a much shorter distance, the blunting of the blade plays a much less significant role in the test results. Through plotting of the results from an initial set of tests onto a scatter graph, force against stroke length can be plotted using a trend line that estimates the force necessary to create a 20 mm stroke length. Once determined, the identified force is applied to the specimen a further five times.
EN 388, 6.3—Tear Resistance
In this test, specimens of material from the palm of four gloves (two from the longitudinal direction and two from the transverse direction) are prepared and clamped in the jaws of a standard tensile strength testing machine. The jaws are moved apart at a constant speed of 100 mm/min and the force needed to tear the material is measured.
For single materials, the performance level is given by the lowest result of the four tests. For multiple-layer unbonded items, each layer is tested individually. Four tests are carried out on each layer and performance is based on the lowest individual result of the most tear-resistant material. EN 388 defines the performance levels as ranging from Level 1, whereby the specimen can resist a peak force between 10N and 25N, to Level 4, where the tear strength is at least 75N.
EN 388, 6.4—Puncture Resistance
Test specimens are again taken from the palm of the glove. In the case of unbonded multiple-layer materials, the layers are assembled and tested as they would be in the glove. The test uses a standard, rounded stylus that is pushed through the specimen at a fixed speed of 100 mm/min using a compression test machine, and the maximum force required for the stylus to penetrate fully through the specimen is measured. Performance levels are based on the lowest of four test results, defined in EN 388 as being from Level 1, with a puncture force of between 20N and 60N, to Level 4, which has a measured resistance of at least 150N.
Specific Protection Tests
BS EN 374 Parts 1 to 4: 2003 to 2013: Protective Gloves Against Chemicals and Micro-Organisms
EN 374 consists of the following parts:
- Part 1: Terminology and performance requirements
- Part 2: Determination of resistance to penetration
- Part 3: Determination of resistance to permeation by chemicals
- Part 4: Determination of resistance to degradation by chemicals
Part 1 details the performance criteria and also includes requirements to check the mechanical and physical integrity of the products and specifies that the glove also must meet the requirements of EN 388:2003. Penetration resistance in part 2 is determined by subjecting the gloves to either air leak or water leak tests to determine whether any hole is present that would allow chemicals to penetrate through to the user’s hand. Part 3 specifies the determination of the resistance of protective glove materials to permeation by potentially hazardous non-gaseous chemicals under the conditions of continuous contact. Permeation is the process by which a chemical moves through a protective glove material on a molecular level; gloves are classified according to the breakthrough time of the chemical through the glove material.
For compliance with the standard as a glove protecting against chemicals, the glove must achieve a permeation result of at least performance Level 2 when tested against three or more of the chemicals from the list of 12. Additional permeation tests against other chemicals specific to a particular end use are also often carried out to demonstrate the suitability of the glove.
Part 4 is the most recently published part of the standard and is applicable to gloves made of natural or synthetic polymer. The resistance of a protective glove material to degradation by a liquid chemical is determined by measuring the puncture resistance change of the glove material after a continuous contact with the external surface with the challenge test chemical.
EN 407:2004—Protective Gloves Against Thermal Risks (Heat and/or Fire)
This is a general standard designed to be used for any glove that is to be produced and sold as providing protection against thermal hazards. The standard includes six thermal tests: burning behavior, contact heat, convective heat, and radiant heat, as well as against small and large splashes of molten metal, plus reference to EN 388 and EN 420 for mechanical and general performance requirements.
EN 12477:2001—Protective Gloves for Welders
EN 12477:2001 is a standard specifically for gloves to be used when welding. It is based on the tests in EN 388, EN 407, and EN 420. Two types of glove are addressed, "Type A" and "Type B." Type B has higher requirements for dexterity to cover use in some specialized welding operations, whereas Type A gloves are intended for other more general welding processes. Gloves intended to be used for arc welding must be tested to EN 1149 for electrical resistance.
EN 659:2003 (+A1:2008) Protective Gloves for Firefighters
This specialist standard is for gloves used in firefighting. It references test procedures from EN 420, EN 388, and EN 407, plus other specific tests for properties such as resistance to water and chemical penetration.
EN 511:2006—Protective Gloves Against Cold
This is a general standard designed to be used for any glove that claims protection against cold environments. The standard includes three specific tests for assessing thermal insulation: convective cold, contact cold, and water penetration, plus low-temperature flexibility tests for coated materials, in addition to requirements from EN 388 and EN 420.
EN 421:2010—Protective Gloves Against Ionizing Radiation and Radioactive Contamination
In addition to reference to the general standards of EN 420, EN 388, and EN 374, this also includes special test procedures to measure the effectiveness of the glove at attenuating/absorbing radiation and its water vapor permeability.
EN 455 Parts 1-4:2000 to 2009—Medical Gloves for Single Use
EN 455 consists of the following parts:
- Part 1: Requirements and testing for freedom from holes
- Part 2: Requirements and testing for physical properties
- Part 3: Requirements and testing for biological evaluation
- Part 4: Requirements and testing for shelf life determination
EN 455 part 1 provides requirements and test methods for checking the production quality of products with respect to the presence of holes in new items. This standard also specifies the number of samples taken for testing purposes is based on the number of gloves produced by the manufacturer in a single batch and is based on a statistical technique using Acceptable Quality Levels (AQL).
EN 455 part 2 assesses the dimensions of the final products and gives requirements for surgical gloves and seamed and unseamed examination gloves. The strength of the material used is also addressed in EN 455 part 2, with tensile strength requirements being given for a range of materials and seamed and unseamed gloves.
Where gloves are manufactured from natural latex, EN 455 part 3 provides a method for assessing the level of soluble proteins present. This is needed because high levels may cause dermatitis to wearers if they are exposed over long periods of time or if a person suffers from an allergy.
EN 455 part 4 contains requirements and testing for shelf life determination for medical gloves for single use. It also specifies the requirements for labeling and information to be supplied with the gloves.
EN 13594:2002—Protective Gloves for Motorcyclists
EN 13594:2002 is a standard that includes tests from both EN 388 and EN 420, in addition to other specialist requirements (specifically impact, abrasion resistance, and seam strength) developed originally for the assessment of motorcyclists' clothing.
EN 381 Parts 4 and 7:1996—Protective Gloves Against Chainsaws
This standard defines a test to measure the cut resistance of the glove against a simulated chainsaw accident and also includes an assessment of the area of protective coverage.
EN 1082 parts 1-3:1996 to 2000—Protective Gloves Against Hand Knives
This is another specialized standard that includes a series of tests to measure a glove’s dimensions, design, protective coverage, and impact cut resistance, in addition to the strength of chainmail.
EN ISO 10819:2013—Protective Gloves Against Mechanical Vibration
This standard is primarily based on a complex test procedure to assess a glove’s performance in attenuating transmitted vibrations.
EN 60903:2003—Gloves for Live Electrical Working
This is a standard developed for testing gloves intended to protect against high voltages. It includes six classes of protection (referenced 00, 0, 1, 2, 3, 4), which cover working voltages from 0.5 to 36 kV ac. The standard includes performance requirements and test procedures to measure electrical and mechanical performance, both before and after a range of pre-treatments.
Summary
As with many of the standards developed as a result of the EU Directive on PPE, the classification of a glove in a particular test is usually defined as one of a series of performance levels (usually between 1 and 4 or 5). It is then left to the user, following a suitable risk assessment exercise, to select a glove with a suitable profile of performance levels in relevant tests.
This article originally appeared in the February 2016 issue of Occupational Health & Safety.
